MikroTik mANT 19s – MTAS 5G-19D120

Productomschrijving

The new sector mANT antennas are the perfect companion for the BaseBox, NetBox, NetMetal or any other outdoor wireless device. The mANT is a dual-polarization 19dBi 120 degree beamwidth antenna with two RP-SMA connectors. It comes with metallic U bolt type mounts.

Specifications mANT 19s

Beamwidth: 120 deg (azimuth) 5 deg (elevation)
Connector: two RP-SMA
Cross Polarization: >30 dB
Diameter x Depth: 152 x 598 x 78 mm
Frequency Range: 5.17 – 5.825 GHz
Front-to-Back Ratio: >30 dB
Polarization: Vertical and horizontal
Port to Port Isolation: >40 dB min
VSWR: 1.43 typ, 1.8 max
Weight: 1270 g

Package Contents

MTAS-5G-19D120, quickMOUNT PRO, K-41 screw kit, Metal ring.

Productspecificaties

Merk

MikroTik

MikroTik

MikroTik mANT 19s – MTAS 5G-19D120

Uitverkocht

Schrijf je in op de wachtlijst om een ​​e-mail te ontvangen wanneer dit product beschikbaar komt

Voor 17:00 besteld, dezelfde dag verzonden.
Reuze assortiment
Voor €5 bij je thuisbezorgd!
Niet goed, geld terug
